Screw jacks

Technical characteristics:

• dynamic load capacity: 5 ÷ 400 kN;
• execution type: translating screw (VT) and rotating screw (VR);
• accessories: protection tube (TQ), position control up-down (PS), bellows (CS), motor flanges (PMG), etc...
• screw jack material: aliuminium AC43100, cast iron G25 UNI 5007, cast iron GS400 UNI 4544, stainless steel AISI 316 (ASTM A 351 CF8M);
• lifting screw material: steel C15 - EN 10277, stainless steel AISI 304;
• nut material: 11SMnPb30 – EN 10277, bronze;
• lifting screw: Tr18x4 ÷ Tr100x12;
• stroke for input turn: 0,17 ÷ 1,42 mm;
• operating temperature: - 5 ˚C ÷ + 40 ˚.
